iPonic 624 Light Output Running 24/7

THIS PRODUCT HAS BEEN DISCONTINUED AND REPLACED BY THE PEARL CONTROL SYSTEM.

https://link4controls.com/link4_controllers/

This Process will allow for a LIGHT output run for 24hrs nonstop utilizing a separate light controller to work independently from iPonic with the High Temp Alarm Still working for Secondary protection. (Have to do a 5 min Timed override for it to work- this is the only time the iPonic High Temp Alarm Cutoff will not work)

You want to do this process for each room

ROOM 1

1^st Go to Room 1 Advance Light Settings:

OK->System Setup->Advance->Room 1->Light Settings (button 4) ->

Set Power cool Down Time to 0

Allow light to run independently from controller – YES

Separate Light Bank – YES

2^nd Go to Room 1 Setpoints and program as follows:

Ok->Setpoints->Room 1->4.Light Setting->Light Timing method (button 8)

Choose “Lights Run Independently from Day setpoint” then OK

3^rd Go back into Room 1 Light Setting and program the Time to be

Start Time: 8am

End Time: 7:58am

Save – and Hit the Home Button

4^th from the Home Screen you want to go into Room 1 Light Output (#1) and set up a Timed Override

From Home Screen press button #1 till TIMED OVR is highlighted then OK.

Enable (Button 1)

Override ON (button 2)

Start Time (button 5) 7:56AM

Duration (button 6) 5 MINUTES

Occur DAILY (Button 7)

OK to SAVE

ROOM 2

1^st Go to Room 2 Advance Light Settings:

OK->System Setup->Advance->Room 2->Light Settings (button 4) ->
